176Vac, the module maximum output power of 100% of the rated power is 3500W;
110Vac, the module maximum power output of 50% of rated power is 1750W;
85Vac, the module maximum power output of 18.75% rated power is 612W.
Below 45℃ ambient temperature, the module can output full power 3500W;
55℃ambient temperature, module maximum output power of 3500W;
60℃ ambient temperature, module maximum output power of 1750W;
65℃ ambient temperature, the maximum output power of the module is zero.
1.Environmental conditions:
Operating Temperature: -5℃ to 45℃, derating above 45℃
Storage temperature: -40℃ to 70℃
Relative humidity: ≤ 95% RH, non-condensing
Altitude: ≤ 2000m (above 2000m derating)
Cooling: forced air-cooled
2. Input characteristics:
Input Voltage Range: 100Vac ~ 270Vac, single-phase three-wire
Rated input voltage: 200VAC ~ 250VAC
The power derating input voltage range: 85Vac ~ 176Vac
Does not work to withstand the maximum the static voltage: 280VAC should be
Rated input current: <20A @ 3500W
Maximum input current: <23A @ 3500W/176Vac
Input inrush current: <30A
Allows you to enter the grid frequency: 45 ~ 65Hz
Rated input grid frequency: 50Hz/60Hz
3. Output characteristics:
Output DC voltage range: 50V
DC output current: 0A to 70A
Regulation accuracy ≤ ± 0.5%
Load regulation rate ≤ ± 0.5%
Voltage regulation rate ≤ ± 0.1%
Boot on the red magnitude ≤ ± 1%
4 module Dimensions:
124.3mm (H) x 84mm (W) x 287mm (D)
5:Weight: ≤ 3.5kg
