CZE-T501 50w FM transmitter is a professional FM transmitter newly released by CZHFM Co.. It’s featured by one button control for all functions. It has VSWR protection, temperature protection, RDS port, electronic volume adjusting,equipped with low pass filters. It’s applicable in many places, such as stadium, county radio station, community radio station, motel, public square,church, theater and so on.
Functions and features:
-1 U-standard chassis
-Power up to 50 watts
-Using digital phase-locked loop frequency synthesizer (PLL) technology, ultra-high frequency stability.
-Have the standing wave protection, and overtemperature protection.
-Output power from 0 ~ 50W continuously adjustable
-Using the power lock feature
-Show the timely output power and various working status.
Operating frequency: 87.5 ~ 108MHz
Output power: 0-50Watt (continuously adjustable)
Output Impedance: 50 ohm
Spurious and harmonic radiation:-60db
Frequency response: 50 ~ 15KHz (3db)
Left and right channel separation: 45db
LINE IN connector: RCA two-channel Cinch (stereo)
The microphone interface: 6.5mm
Microphone Type: Dynamic microphone (electret microphone is not applicable)
Power supply part:
Rated working voltage: AC 100 ~ 120V /200 ~ 240V / 50/60Hz (you can switch the voltage inside the chassis)
Maximum power consumption: 100W
1. Make sure the antenna or the Load can be ground connected to transmitter
2. The power supply voltage must be within the allowed range.
3.Make sure the fan ventilation is good.
1*CZE-T501 50W FM transmitter
With a good antenna the FM transmitter will broadcast better. The transmission range depends on many factors. The true distance is based on the sensitivity of the receiver, antenna of the receiver, building and other obstructions which are between the transmitter and receiver. The distance will much more in open countryside.
High quality all band 87-108MHZ antenna is available, please check item Whole Aluminum GP Antenna if you need.
