2KW 2 bay Dipole Antenna for Professional FM Transmitter

  • Model: 2KW-2-WAY-ANT
  • Shipping Weight: 12000g
  • 20 Units in Stock

 Ask a Question

$720.00

Add to Cart:

2 Bay FM Dipole Antenna used for FM radio broadcasting system, to receive FM radio transmitter output power signal and send the signal out efficiently. Can use multiple antenna multi-antenna array to enhance the gain of the transmitting antenna.
1.A Dipole Antenna is a radio antenna that can be made of aluminum, copper, and bronze tube with a center-fed driven element. It consists of two metal conductors of rod, oriented parallel and collinear with each other (in line with each other), with a small space between them.
2. The dipole antenna is a particularly important form of RF antenna which is very widely used for radio transmitting and receiving applications. The dipole is often used on its own as an RF antenna, but it also forms the essential element in many other types of RF antenna. As such it is the possibly the most important form of RF antenna.
3. A half-wave dipole antenna means the length of this dipole antenna is equal to a half-wavelength at the frequency of operation.

2KW-2-BAY-DIPOLE-ANTENNA

Package Include:

2 x 1Kw dipole antenna

1 x 3kw power splitter

2 x 3 meter 50-9 jumper cable

ANTENNA FEATURES:

2000Watt Band II dipole, Broadband 87.5~108 MHz, 1.5 dBd gain, Vertical Polarization, Omni directional pattern.

Frequency range: 87.5-108Mhz

Impedance: 50 Ohm

Connectors: N (L16) -female

Max Power: 1000 Watt

VSWR: <1.35:1

Size: 1424mm x 995mm x 50mm

Frequency Range: 87.5-108Mhz

Power Splitter FEATURES:

3KW FM 2-Way Power Splitter / 88MHz to 108MHz

Frequency Range: 88-108hz

VSWR: 1.1

Power Handling: 3000 Watts

Connectors: DIN (L29) female

Dimensions: 850 x 45 x 45 mm

Jumper FEATURES:

3 meter DIN male to N male connector 50Ohm jumper 50-9 coaxial cable

Suitable for connection from power splitter to antenna

length: 3 meter

Impedance: 50 ohm

cable Type:50-9 Corrugated coaxial cable

connectors A:DIN(L29) male

connectors B:N(L16) male
